Intel Ethernet Controller I350-AM2 以太网控制器NHI350AM2 SLJ3S SLJ3R

Essentials

• Product CollectionIntel® Ethernet Controller I350 Series

• Code NameProducts formerly Powerville

• StatusLaunched

• Launch DateQ2'11

• Expected Discontinuance1H'29

• TDP2.8 W

• Operating Temperature Range-10°C to 55°C

• Operating Temperature (Maximum)55 °C

• Operating Temperature (Minimum)-10 °C


Supplemental Information

• DatasheetView now

• Product BriefView now


Networking Specifications

• Port ConfigurationDual

• Data Rate Per Port1GbE

• System Interface TypePCIe v2.0 (5.0 GT/s)

• NC Sideband InterfaceYes

• Jumbo Frames SupportedYes

• Interfaces Supported1000Base-T, SGMII, SERDES


Package Specifications

• Package Size17mm x 17mm


Intel® Virtualization Technology for Connectivity

• On-chip QoS and Traffic ManagementYes

• Virtual Machine Device Queues (VMDq)Yes

• PCI-SIG* SR-IOV CapableYes


Advanced Technologies

• Intel® Virtualization Technology for Connectivity (VT-c)Intel® VT-c

• Fiber Channel over EthernetNo

• IEEE 1588Yes

• iWARP/RDMANo

• Intel® Data Direct I/O TechnologyYes
